Salient Features:
Model | Ton Cap. | Bending Cap. mm(M.S.) | Table Height | Table Width | Clear Distance | Depth | Ram Stroke | Open height | Power H.P. | Ram Speed | Over all Dimension(L x W x H) | Approx Weight in kgs. |
SPBR-0212 | 20 | 1270x2 | 800 | 150 | 900 | 200 | 100 | 250 | 3 | 35-9-55 | 1450x1100x1900 | 1200 |
SPBR-0312 | 30 | 1270x3 | 800 | 150 | 900 | 200 | 100 | 250 | 3 | 35-9-55 | 1450x1100x1900 | 1400 |
SPBR-0412 | 40 | 1270x4 | 800 | 150 | 900 | 200 | 100 | 250 | 3 | 35-9-55 | 1450x1250x2050 | 1800 |
SPBR-0512 | 50 | 1270x5 | 800 | 180 | 900 | 200 | 125 | 250 | 5 | 30-7-55 | 1450x1500x2200 | 2300 |
SPBR-0612 | 60 | 1270x6 | 850 | 180 | 900 | 200 | 125 | 350 | 5 | 30-5-30 | 1450x1500x2350 | 2500 |
SPBR-0812 | 80 | 1270x8 | 850 | 200 | 900 | 250 | 150 | 330 | 7.5 | 37-6-41 | 1450x1700x2500 | 2700 |
SPBR-1012 | 100 | 1270x10 | 900 | 200 | 900 | 250 | 150 | 330 | 7.5 | 37-6-41 | 1450x1700x2500 | 3500 |
SPBR-1212 | 120 | 1270x12 | 900 | 230 | 900 | 300 | 150 | 330 | 10 | 40-5-40 | 1500x1850x2600 | 4500 |
SPBR-1612 | 160 | 1270x16 | 900 | 230 | 900 | 300 | 200 | 375 | 15 | 40-5-40 | 1500x1850x2600 | 5000 |
SPBR-0215 | 20 | 1525x2 | 800 | 150 | 1100 | 200 | 100 | 250 | 3 | 35-9-55 | 1700x1100x1900 | 1500 |
SPBR-0415 | 40 | 1525x3 | 800 | 150 | 1100 | 200 | 100 | 250 | 3 | 30-7-55 | 1700x1100x1900 | 2000 |
SPBR-0515 | 50 | 1525x4 | 800 | 180 | 1100 | 200 | 125 | 330 | 5 | 30-7-55 | 1700x1200x2000 | 2300 |
SPBR-0615 | 60 | 1525x5 | 850 | 180 | 1100 | 200 | 125 | 330 | 5 | 30-5-30 | 1750x1550x2000 | 2500 |
SPBR-0815 | 80 | 1525x6 | 850 | 200 | 1100 | 250 | 150 | 330 | 7.5 | 37-6-41 | 1750x1550x2300 | 2700 |
SPBR-1015 | 100 | 1525x8 | 900 | 200 | 1100 | 250 | 150 | 330 | 7.5 | 37-6-41 | 1750x1700x2500 | 4000 |
SPBR-1215 | 120 | 1525x10 | 900 | 230 | 1100 | 300 | 150 | 330 | 10 | 40-5-40 | 1750x1850x2600 | 5000 |
SPBR-1615 | 160 | 1525x12 | 900 | 230 | 1100 | 300 | 200 | 375 | 15 | 40-5-40 | 1750x1850x2600 | 5500 |
SPBR-2015 | 200 | 1525x16 | 900 | 250 | 1100 | 300 | 200 | 375 | 20 | 37-5-37 | 1750x1850x2600 | 6000 |
SPBR-0320 | 30 | 2030x2 | 800 | 150 | 1500 | 200 | 100 | 250 | 3 | 30-7-55 | 2200x1100x1900 | 1700 |
SPBR-0520 | 50 | 2030x3 | 800 | 180 | 1500 | 200 | 125 | 330 | 5 | 30-7-55 | 2200x1100x1900 | 2700 |
SPBR-0620 | 60 | 2030x4 | 850 | 180 | 1500 | 200 | 125 | 330 | 5 | 30-5-30 | 2200x1100x1900 | 3100 |
SPBR-0820 | 80 | 2030x5 | 850 | 200 | 1500 | 250 | 150 | 330 | 7.5 | 37-6-41 | 2250x1200x2000 | 3600 |
SPBR-1020 | 100 | 2030x6 | 850 | 200 | 1500 | 250 | 150 | 330 | 7.5 | 37-6-41 | 2250x1500x2000 | 4500 |
SPBR-1220 | 120 | 2030x8 | 900 | 230 | 1500 | 300 | 150 | 330 | 10 | 40-5-40 | 2250x1500x2000 | 5500 |
SPBR-1620 | 160 | 2030x10 | 900 | 230 | 1500 | 300 | 150 | 375 | 15 | 40-5-40 | 2250x1800x2500 | 6500 |
SPBR-2020 | 200 | 2030x12 | 900 | 250 | 1500 | 300 | 200 | 375 | 20 | 37-5-37 | 2250x2000x2600 | 7000 |
SPBR-2520 | 250 | 2030x16 | 900 | 250 | 1500 | 300 | 200 | 375 | 25 | 37-5-37 | 2250x2150x2700 | 8000 |
SPBR-3020 | 300 | 2030x20 | 900 | 280 | 1500 | 350 | 200 | 425 | 30 | 37-5-37 | 2250x2150x2700 | 9000 |
SPBR-4020 | 400 | 2030x25 | 950 | 300 | 1500 | 350 | 250 | 450 | 40 | 30-5-34 | 2250x2250x3000 | 15500 |
SPBR-5020 | 500 | 2030x30 | 950 | 350 | 1500 | 350 | 250 | 450 | 50 | 28-5-28 | 2250x23003000 | 18000 |
SPBR-0425 | 40 | 2540x2 | 800 | 150 | 2000 | 200 | 100 | 250 | 3 | 30-7-55 | 2750x1100x1900 | 2500 |
SPBR-0625 | 60 | 2540x3 | 800 | 180 | 2000 | 200 | 125 | 330 | 5 | 30-5-30 | 2750x1100x1900 | 3500 |
SPBR-0825 | 80 | 2540x4 | 850 | 200 | 2000 | 250 | 150 | 330 | 7.5 | 37-6-41 | 2700x1200x2000 | 4200 |
SPBR-1025 | 100 | 2540x5 | 850 | 200 | 2000 | 250 | 150 | 330 | 7.5 | 37-6-41 | 2700x1500x2200 | 5000 |
SPBR-1225 | 120 | 2540x6 | 850 | 230 | 2000 | 300 | 150 | 330 | 10 | 40-5-40 | 2700x1500x2200 | 5700 |
SPBR-1625 | 160 | 2540x8 | 900 | 230 | 2000 | 300 | 200 | 375 | 15 | 40-5-40 | 2700x1750x2500 | 7000 |
SPBR-2025 | 200 | 2540x10 | 900 | 250 | 2000 | 300 | 200 | 375 | 20 | 37-5-37 | 2700x1800x2600 | 8500 |
SPBR-2525 | 250 | 2540x12 | 900 | 250 | 2000 | 300 | 200 | 375 | 25 | 367-5-37 | 2700x2000x2700 | 10000 |
SPBR-3025 | 300 | 2540x16 | 900 | 280 | 2000 | 300 | 200 | 425 | 30 | 37-5-37 | 2700x2000x2700 | 11500 |
SPBR-4025 | 400 | 2540x20 | 950 | 300 | 2000 | 350 | 250 | 450 | 40 | 30-5-34 | 2700x2200x2900 | 18000 |
SPBR-5025 | 500 | 2540x25 | 950 | 350 | 2000 | 350 | 250 | 450 | 50 | 28-5-28 | 2700x2250x3000 | 21500 |
SPBR-0530 | 50 | 3125x2 | 850 | 180 | 2500 | 200 | 125 | 330 | 5 | 30-7-55 | 3350x1200x2000 | 3500 |
SPBR-0830 | 80 | 3125x3 | 850 | 200 | 2500 | 250 | 150 | 330 | 7.5 | 37-6-41 | 3350x1500x2200 | 4500 |
SPBR-1030 | 100 | 3125x4 | 900 | 200 | 2500 | 250 | 150 | 330 | 7.5 | 37-6-41 | 3350x1700x2400 | 5300 |
SPBR-1230 | 120 | 3125x5 | 900 | 230 | 2500 | 300 | 150 | 330 | 10 | 40-5-40 | 3350x1750x2500 | 6500 |
SPBR-1630 | 160 | 3125x6 | 900 | 230 | 2500 | 300 | 200 | 375 | 15 | 40-5-40 | 3350x1850x2500 | 8000 |
SPBR-2030 | 200 | 3125x8 | 900 | 250 | 2500 | 300 | 200 | 375 | 20 | 37-5-37 | 3350x2000x2600 | 9800 |
SPBR-2530 | 250 | 3125x10 | 900 | 250 | 2500 | 300 | 200 | 375 | 25 | 37-5-37 | 3350x2100x2800 | 11000 |
SPBR-3030 | 300 | 3125x12 | 900 | 280 | 2500 | 350 | 200 | 425 | 30 | 37-5-37 | 3350x2200x2900 | 13000 |
SPBR-4030 | 400 | 3125x16 | 950 | 300 | 2500 | 350 | 250 | 450 | 40 | 30-5-34 | 3350x2200x2900 | 20000 |
SPBR-5030 | 500 | 3125x20 | 950 | 350 | 2500 | 350 | 250 | 450 | 50 | 28-5-28 | 3350x2400x3300 | 2200 |
SPBR-0640 | 60 | 4000x2 | 850 | 180 | 3000 | 200 | 125 | 330 | 5 | 30-5-30 | 4200x1500x2200 | 4000 |
SPBR-1040 | 100 | 4000x3 | 850 | 200 | 3000 | 250 | 150 | 330 | 7.5 | 37-6-41 | 4250x1600x2300 | 6000 |
SPBR-1240 | 120 | 4000x4 | 900 | 230 | 3000 | 300 | 150 | 330 | 10 | 40-5-40 | 4250x1700x2350 | 8000 |
SPBR-1640 | 160 | 4000x5 | 900 | 230 | 3000 | 300 | 200 | 375 | 15 | 40-5-40 | 4250x1700x2550 | 9000 |
SPBR-2040 | 200 | 4000x6 | 900 | 250 | 3000 | 300 | 200 | 375 | 20 | 37-5-37 | 4250x1850x2600 | 10000 |
SPBR-2540 | 250 | 4000x8 | 900 | 250 | 3000 | 300 | 200 | 375 | 25 | 37-5-37 | 4250x2100x2600 | 12500 |
SPBR-3040 | 300 | 4000x10 | 900 | 280 | 3000 | 300 | 200 | 425 | 30 | 37-5-37 | 4250x2150x2700 | 15000 |
SPBR-4040 | 400 | 4000x12 | 950 | 300 | 3000 | 350 | 250 | 450 | 40 | 30-5-34 | 4250x2200x2900 | 21000 |
SPBR-5040 | 500 | 4000x16 | 950 | 350 | 3000 | 350 | 250 | 450 | 50 | 28-5-28 | 4250x2300x3000 | 23000 |
SPBR-1250 | 120 | 5000x3 | 850 | 230 | 4000 | 300 | 200 | 330 | 10 | 40-5-40 | 5250x1800x2400 | 8500 |
SPBR-1650 | 160 | 5000x4 | 900 | 230 | 4000 | 300 | 200 | 375 | 15 | 40-5-40 | 5250x1900x2500 | 9500 |
SPBR-2030 | 200 | 5000x5 | 900 | 2502 | 4000 | 300 | 200 | 375 | 20 | 37-5-37 | 5250x2000x2600 | 11000 |
SPBR-2550 | 250 | 5000x6 | 900 | 250 | 4000 | 300 | 200 | 375 | 25 | 37-5-37 | 5250x2100x2700 | 13000 |
SPBR-3050 | 300 | 5000x8 | 900 | 250 | 4000 | 350 | 200 | 425 | 30 | 37-5-37 | 5250x2200x2900 | 16000 |
SPBR-4050 | 400 | 5000x10 | 950 | 300 | 4000 | 350 | 250 | 450 | 40 | 30-5-34 | 5250x2300x3000 | 23000 |
SPBR-5050 | 500 | 5000x12 | 950 | 350 | 4000 | 350 | 250 | 450 | 50 | 28-5-28 | 5250x2400x3300 | 25000 |
SPBR-1660 | 160 | 6000x3 | 900 | 230 | 5000 | 300 | 200 | 375 | 15 | 40-5-40 | 6250x1900x2600 | 11500 |
SPBR-2060 | 200 | 6000x4 | 900 | 250 | 5000 | 300 | 200 | 375 | 20 | 37-5-37 | 6250x2100x2750 | 13000 |
SPBR-2560 | 250 | 6000x5 | 900 | 250 | 5000 | 300 | 200 | 375 | 25 | 37-5-37 | 6250x2100x2800 | 16000 |
SPBR-3060 | 300 | 6000x6 | 900 | 280 | 5000 | 300 | 200 | 425 | 30 | 37-5-37 | 6250x2200x3000 | 20000 |
SPBR-4060 | 400 | 6000x8 | 950 | 300 | 5000 | 350 | 250 | 450 | 40 | 30-5-34 | 6250x2200x3100 | 24000 |
SPBR-5060 | 500 | 6000x10 | 950 | 350 | 5000 | 350 | 250 | 450 | 50 | 28-5-28 | 6250x2300x3300 | 27000 |
SPBR-6060 | 600 | 6000x12 | 950 | 400 | 5000 | 350 | 250 | 450 | 60 | 25-4-25 | 6250x2350x3400 | 3000 |
