40 MM Drilling Machine

40 MM Drilling Machine
40 MM Drilling Machine
Product Code : 40-1000-dc
Product Description
CAPACITY 40MM
Drilling [C.I.] 45
Drilling [M.S.] 40
Boring [M.S.] 80
Tapping [C.I.] 20
Tapping [M.S.] 16
Drilling Head
Spindle Nose M.T.-4
Spindle Nose Outside Diameter 60
Ram Diameter 80
Travel of Spindle 250
Number of Spindle 12
Speed Min./Mix. 55 - 1500
Number of Power Feeds 3
Range of Power Feeds 0.10 + 0.3
Power
Drilling Head 2 HP
Two Speed Motor 1440 + 2800
Lighting of Arm 1 HP
  1440
Working Range
Column Diameter 220
Dist. From Spindle to base min./mix. 400 x 1100
Dist. From Column to centre min./mix. 250 x 1080
Horizontal Movement of Drilling Wheel 800
Drilling Radius 1110
Traverse of Arm 600
Base Plate
Height of Base Plate 180
Working Surface 800 x 1150
Number of T Sloth Length 3
Width of Cast Side 18 mm
Oerall Dimensions [ L x W x H ] 1640 x 810 x 2160
Weight
Approximate 1600 kg.
