All Geared Pillar Drilling Machine Heavy Duty: Vikas
185000.0 INR/Piece
Product Details:
- Features All Geared, Sturdy Construction, Heavy Duty Operation, Adjustable Table
- Cooling System Provision for Coolant System
- Voltage 415 V (Three Phase)
- Frequency 50 Hz
- Power Rating 2.2 kW
- Operating Temperature 5C to 45C
- Production Capacity Designed for heavy duty, batch production
- Click to view more
X
All Geared Pillar Drilling Machine Heavy Duty: Vikas Price And Quantity
- 185000.0 INR/Piece
- 1 Piece
All Geared Pillar Drilling Machine Heavy Duty: Vikas Product Specifications
- Centralized Lubrication System
- Pillar Column Type
- Painted & Powder Coated
- All Geared Mechanical Transmission
- Electric
- Vikas (Brand/Model)
- Standard Electrical Connection
- 3 HP/2.2 kW
- Approx. 900 x 600 x 2000 mm
- Vertical Pillar Drilling Machine
- All Geared Pillar Drilling Machine Heavy Duty
- < 80 dB
- Push Button Control
- 3 HP
- Approximately 450-600 kg
- All Geared, Sturdy Construction, Heavy Duty Operation, Adjustable Table
- 415 V (Three Phase)
- Provision for Coolant System
- 50 Hz
- 2.2 kW
- 5C to 45C
- Designed for heavy duty, batch production
- Drilling, Reaming, Tapping in workshops, production and maintenance units
- All Geared Mechanical Drive
- High Drilling Accuracy
- Automatic/Semi-Automatic
- Industrial Green
- Manual with T-Slots
- 40-50 mm
- Multi-speed (Gear Controlled)
- 1000 mm (Approx.)
- 200 mm (Approx.)
- 350 mm (Approx.)
- 150 mm
- Rack and Pinion Elevation for Table
- Electrical Interlock and Emergency Stop Switch
- Optional Attachment Available
- MT-4
- 360 Rotatable and Height Adjustable
- 8-12 Steps (Depending on Model)
- 700 x 700 mm
- Anticorrosive Paint with Hardened Components
- 90 to 1600 RPM (Variable Gears)
- 420 x 420 mm
- Cast Iron, Steel Components
Product Description
40 MM ALL GEARED HEAVY DUTY PILLAR DRILLING MACHINE
Vikas Machinery offers a high-performance 40 MM All Geared Pillar Drilling Machine designed for precision drilling and heavy-duty industrial applications. Built with a strong and rigid machine structure, this drilling machine provides excellent stability, smooth operation, and reliable performance during continuous working conditions.
The machine is equipped with an all-geared transmission system that ensures efficient power transmission and dependable spindle performance. With a maximum drilling capacity of 40 MM, it is suitable for drilling operations on mild steel, cast iron, steel, and various other engineering materials. The robust construction helps reduce vibration and provides accurate and consistent drilling results.
This Heavy Duty Pillar Drill Machine is suitable for engineering workshops, fabrication units, automobile industries, manufacturing plants, maintenance departments, machine shops, and general metalworking applications. The sturdy work table provides proper support for different workpieces, while the geared mechanism allows convenient operation and efficient drilling.
Manufactured using quality components, the machine is designed for long service life, minimum maintenance, and dependable industrial performance. Its user-friendly operation makes it suitable for both regular workshop jobs and demanding production environments.
Key Features: 40 MM drilling capacity, heavy-duty construction, all-geared gearbox, rigid machine body, smooth spindle operation, excellent drilling accuracy, low vibration, durable components, easy maintenance, and long-lasting performance.
Choose Vikas Machinery's 40 MM All Geared Pillar Drilling Machine for reliable, accurate, and efficient drilling performance in industrial and workshop applications.
Engineered for Reliability and Power
The Vikas All Geared Pillar Drilling Machine boasts sturdy construction using high-quality cast iron and steel, with anticorrosive finishing and hardened components. Designed for heavy-duty use, it supports automatic or semi-automatic operation and is well-suited for both small workshops and industrial batch production environments.
Ease of Operation and Versatility
This machine features a push-button control system, 360-degree rotatable and height-adjustable table, and gear-driven speed changes, making setup and operation simple. The rack-and-pinion elevation for the table and centralized lubrication system ensure smooth handling and reduced maintenance downtime.
Precision Meets Safety
Achieve high drilling accuracy with variable spindle speeds and a robust clamping system with T-slots. Enhanced safety is provided by an electrical interlock and an emergency stop switch, ensuring both machine and operator protection during intensive production.
FAQ's of All Geared Pillar Drilling Machine Heavy Duty: Vikas:
Q: How does the gear-controlled speed system benefit my production process?
A: The gear-controlled multi-speed system allows you to adjust spindle speeds (from 90 to 1600 RPM) across 8-12 steps depending on the model, enabling optimal speed selection for various materials and drilling tasks. This results in increased efficiency and precision for both batch production and custom jobs.Q: What applications can this drilling machine be used for?
A: The Vikas All Geared Pillar Drilling Machine is suitable for drilling, reaming, and tapping operations, making it versatile for workshops, production lines, and maintenance units. Its heavy-duty construction and high drilling capacity accommodate a wide range of industrial applications.Q: When should I consider using the automatic feeder attachment?
A: The optional automatic feeder attachment is recommended for high-volume or repetitive drilling tasks, as it enhances productivity and consistency by automating the feed process. This is especially useful in batch production environments.Q: Where can this machine be installed and used?
A: This machine is designed for use in industrial settings, including workshops, factories, and production plant floors. Its approximate dimensions and standard three-phase electrical connectivity allow straightforward installation in most professional environments across India.Q: What safety features are included with the machine?
A: The All Geared Pillar Drilling Machine includes an electrical interlock system and an emergency stop switch to ensure operator safety. Additionally, its robust design and stable construction further minimize risks associated with heavy-duty machining.Q: How do I maintain the machine for optimal performance?
A: Routine maintenance involves using the centralized lubrication system, cleaning the machine regularly, checking the gear and spindle alignment, and ensuring all safety systems are functional. Anticorrosive finishing and hardened parts also reduce the need for frequent servicing.Q: What are the key benefits of choosing this Vikas model for my facility?
A: Key advantages include high drilling accuracy, multiple speed options, heavy-duty capacity, safety systems, and durability. Its flexible table movement and optional attachments provide adaptability for evolving production needs, making it a long-term asset for your operations.Tell us about your requirement
