Rotary Milling Table

Rotary Milling Table

10000 INR

Product Details:

  • Tool Type Rotary Milling Table
  • Material Stainless Steel
  • Click to view more
X

Price And Quantity

  • 10000 INR
  • 1 Unit

Product Specifications

  • Rotary Milling Table
  • Stainless Steel

Trade Information

  • Cheque, Cash in Advance (CID), Cash Advance (CA)
  • 1 Week
  • Yes
  • Within a certain price range free samples are available
  • Africa, Middle East, Asia
  • All India

Product Description

Rotary Milling Table

Specifications
Size in inches 6 8 10 12 15 18 20
Dia of Table (in mm) 150 200 250 300 375 450 500
Table T-Slot Size (in mm) 10 13 13 16 16 20 20
Centre Bush Bore (morse taper) 2 3 3 3 3 4 4
Worm & Gear Ratio 1:72 1:72 1:72 1:120 1:120 1:120 1:120
Wheel Calibration ( in minutes ) 2 2 2 1 1 1 1
Height Overall (in mm) 715E Vertical 240 300 365 425 530 620 620
Height Overall (in mm)
715 & 715E Horizontal (in mm)
95 105 110 130 135 160 160
Weight (app. in Kgs) Code 715 14 23 36 55 95 162 177
Base to centre 715E 125 160 180 220 265 315 315
Weight (app. in Kgs) Code 715E 16 27 42 65 100 175 187
